Stand-On Operation
Designed for frequent access and quick handling.
Multi directional Forklift
3.0 Ton Stand-On Multi-Directional Forklift
Key Specification Bullets
- Model: 1MQB30
- Capacity: 3000 kg
- Lift Height: Up to 8000 mm
Description
The 1MQB30 stand-on multi-directional forklift is designed for narrow aisle long-material handling where fast access, flexible travel and compact operation are required. With 3000 kg capacity, stand-on operation, four-wheel steering, wide fork adjustment and multi-directional travel, it gives customers a practical solution for frequent long-load movement.
Product Features
Product Highlights
Key features designed to support safer, more efficient and more productive material handling.
MiMA
3.0 Ton Capacity
Handles medium-duty long materials.
MiMA
Multi-Directional Travel
Straight, sideways, diagonal and rotation modes.
MiMA
Four-Wheel Steering
Improves flexibility in narrow areas.
MiMA
All-Wheel Braking
Improves braking on slippery surfaces.
MiMA
High-Lift Mast
Supports stacking up to 8000 mm.
Product Data
Technical Specifications
Compare the available 1MQB30 configurations and discuss the required capacity, lift height and operating environment with our team.
| Specification | 1MQB30 |
|---|---|
| Model | 1MQB30 |
| Operation Type | Stand-on |
| Load Capacity | 3000kg |
| Lift Height | Up to 8000 mm |
| Mast Type | Triplex Full Free Mast |
| Fork Outside Spread | 2860 mm |
| Aisle Width | > 2500 mm |
| Battery Specification | Lithium: 48V / 460Ah |
Product Overview
Product Details
For Frequent Long-Load Movement
- Designed for customers who frequently move long materials in narrow aisles or compact warehouse areas.
- The stand-on design allows fast entry and exit for cyclic loading, transfer and stacking tasks.
- Dealers can position the 1MQB30 as a compact, efficient option for customers needing faster long-load handling.
Compact Operation in Narrow Aisles
- Multi-directional travel allows the truck to move straight, sideways, diagonally and rotate in place.
- This helps long materials move through narrow aisles without requiring large turning areas.
- Customers benefit from better space utilisation and smoother material flow.
Stand-On Design for Faster Workflow
- Stand-on operation is useful where operators frequently enter and exit the truck.
- It can improve efficiency in high-turnover storage and production logistics environments.
- This makes the 1MQB30 suitable for warehouses that prioritise speed, access and compact movement.
Flexible Steering and Braking Control
- Four-wheel steering improves manoeuvrability in restricted working areas.
- All-wheel braking improves stopping performance on demanding or slippery surfaces.
- These features help customers improve control and safety during long-load movement.
Useful Complement for Dealer Portfolios
- The 1MQB30 gives dealers a stand-on multi-directional model for customers who do not need a larger seated unit.
- It is suitable for narrow aisle long-material applications where compact operation is important.
- This helps dealers cover more customer scenarios within the long-material handling market.
Product Support
Frequently Asked Questions
Find answers to common questions about 1MQB30. For application-specific advice, contact MiMA Australia.
What is the capacity of the 1MQB30?
The 1MQB30 has a rated load capacity of 3000 kg.
What type of operation does the 1MQB30 use?
It uses stand-on operation, which is suitable for frequent access and high-turnover handling tasks.
Is the 1MQB30 suitable for long materials?
Yes. It is designed for long-material handling in narrow aisle environments.
What is the maximum lift height?
The 1MQB30 supports lift heights up to 8000 mm.
What battery does the 1MQB30 use?
The 1MQB30 uses a 48V / 460Ah lithium battery.
Can I request the full technical data sheet?
Yes. Contact MiMA to receive the full technical specification.
